24 Volt battery bank for a stand alone system

Inverter/Charger 12 Volt - Inverter 240 V A/C 2500 Watt - Battery charger 12 Volt 120 Amp

12 volt 30 amp Charger

PL40 BP Solar Regulator 24 Volts 40 Amps

Fuse disconnect switch for inverter/charger isolates both Negative & Positive leads

Remote for Outback inverter/charger

Solar regulator installed on house boat 12 Volt 60 Amps

Outback Inverter/Charger 24 Volts d/c to 240V a/c

 Caravan power system layout
